Product Details:
|
| Features: | Built-in Smart BMS | Battery Type: | LiFePO4, Lithium Ion Battery |
|---|---|---|---|
| Battery Cell: | Lifepo4 | Battery Size: | 12.8V 70AH |
| Weight: | 10KG | Size: | 260*168*209mm |
| Module/Protocol: | Support Customization | Application: | BOATS, Golf Carts, SUBMARINES, Electric Folklifts,solar Systems,RV |
| OEM/ODM: | Support Customization | Port: | YANTIAN |
| High Light: | 70ah 12V 24V Battery,Rechargeable Golf Cart Battery,Lithium Ion Electric Vehicle battery |
||
| Essential Information | Product Name | 12V70AH LiFePo4 Battery |
| Brand | enersour | |
| Material | Lithium iron phosphate battery cell | |
| Nominal Voltage | 12.8V | |
| Nominal Capacity | 70Ah | |
| Energy | 896Wh | |
| Internal Resistance | ≤20mΩ | |
| Cycle Life | >4000 cycles @0.5C 90% DOD | |
| Charging Parameters | Charge Voltage | 14.4V |
| Charge Current | 1-50A | |
| Max. Charge Current | 50A | |
| Discharge Parameter | Constant Discharge Current | 100A |
| Discharge stop voltage | 10V | |
| Peak Current | 150A , ＜5s | |
| Packaging Information | Battery Case | ABS |
| Terminal | M8 | |
| Outer package size | 300*210*250mm | |
| weight | 9kg | |
| Normal operating temperature | Charge Temperature | 0~45ºC |
| Discharge Temperature | -20~60ºC | |
| Storage Temperature | 0~40ºC |
|
Nominal
Voltage |
Typical
Capacity |
Charge
|
Discharge
|
(mm)
Dimension |
(KG)
Weight |
|
12V
|
12AH
|
0.2C-1C
|
0.2C-2C
|
L151*W99*H84
|
1.5
|
|
12V
|
50AH
|
0.2C-1C
|
0.2C-2C
|
L223*W120*H175
|
6
|
|
12V
|
100AH
|
0.2C-1C
|
0.2C-2C
|
L256*W165*H210
|
12
|
|
12V
|
150AH
|
0.2C-1C
|
0.2C-2C
|
L406*W173*H236
|
17.5
|
|
12V
|
200AH
|
0.2C-1C
|
0.2C-1C
|
L490*W171*H240
|
19
|
|
12V
|
300AH
|
0.2C-1C
|
0.2C-1C
|
L521*W238*H218
|
23
|
|
12V
|
400AH
|
0.2C-1C
|
0.2C-1C
|
L521*W238*H218
|
32
|
|
24V
|
30AH
|
0.2C-1C
|
0.2C-2C
|
L521*W238*H219
|
12
|
|
24V
|
50AH
|
0.2C-1C
|
0.2C-2C
|
L256*W165*H210
|
12
|
|
24V
|
100AH
|
0.2C-1C
|
0.2C-2C
|
L490*W171*H240
|
19
|
|
24V
|
150AH
|
0.2C-1C
|
0.2C-2C
|
L521*W238*H218
|
23
|
|
24V
|
200AH
|
0.2C-1C
|
0.2C-1C
|
L521*W238*H218
|
32
|
|
24V
|
250AH
|
0.2C-1C
|
0.2C-1C
|
L460*W300*H200
|
36
|
|
24V
|
300AH
|
0.2C-1C
|
0.2C-1C
|
L460*W300*H240
|
48
|
|
48V
|
50AH
|
0.2C-1C
|
0.2C-2C
|
L490*W171*H240
|
19
|
|
48V
|
75AH
|
0.2C-1C
|
0.2C-2C
|
L460*W360*H160
|
35
|
|
48V
|
100AH
|
0.2C-1C
|
0.2C-2C
|
L450*W350*H150
|
32
|
|
48V
|
200AH
|
0.2C-1C
|
0.2C-1C
|
L500*W360*H230
|
65
|
|
48V
|
250AH
|
0.2C-1C
|
0.2C-1C
|
customized size
|
|
|
48V
|
300AH
|
0.2C-1C
|
0.2C-1C
|
customized size
|
|
