Product Details:
|
| Battery Type: | LiFePO4 | Battery Type: | Lithium Ion Battery Pack |
|---|---|---|---|
| Battery Cell: | Lifepo 4 | Weight: | 11kg |
| Size: | 330*173*215mm | Housing: | ABS |
| Protection: | Built-in Smart BMS | Application: | BOATS, Golf Carts, SUBMARINES, Electric Folklifts,solar Systems |
| OEM/ODM: | Support Customization | Port: | YANTIAN |
| High Light: | Submarines 12v Lithium Ion Battery,ABS Housing 12v Lithium Ion Battery,BMS Rechargeable Lifepo4 Battery Pack |
||
|
Electrica Characteristics |
Nominal Voltage
|
12.8V
|
|
|
Nominal Capacity
|
100Ah
|
|
|
Energy
|
1280Wh
|
|
|
Internal Resistance
|
≤20mΩ
|
|
|
Cycle Life
|
≥4000 cycles @1C 100%DOD
|
|
|
Months Self Discharge
|
<3%
|
|
|
Efficiency of Charge
|
100% @0.5C
|
|
|
Efficiency of Discharge
|
96~99% @1C
|
|
Standard Charge |
Charge Voltage
|
14.6±0.2V
|
|
|
Charge Mode
|
0.2C to 14.6V, then 14.6V,charge current to 0.02C (CC/CV)
|
|
|
Charger Current
|
50A
|
|
|
Max. Charge Current
|
170A
|
|
|
Charge Cut-off Voltage
|
14.6V±0.2V
|
|
Standard Discharge |
Continuous Current
|
100A
|
|
|
Max. Pulse Current
|
300A(<10s)
|
|
|
Discharge Cut-off Voltage
|
9.2V
|
|
Environmental |
Charge Temperature
|
0 ℃ to 45 ℃ (32F to 113F) @60±25% Relative Humidity
|
|
|
Discharge Temperature
|
-20 ℃ to 60 ℃ (-4F to 140F) @60±25% Relative Humidity
|
|
|
Storage Temperature
|
0 ℃ to 40 ℃ (32F to 104F) @60±25% Relative Humidity
|
|
|
Water Dust Resistance
|
IP56
|
|
Mechanical |
Cell & Method
|
4S1P
|
|
|
Plastic Case
|
ABS
|
|
|
Dimensions (in./mm.)
|
330*173*215mm
Customized |
|
|
Weight (lbs./kg.)
|
11kg
|
|
|
Terminal
|
T11
|
|
|
Protocol (optional)
|
SMBus/RS485/RS232
|
|
|
SOC (optional)
|
LED
|
