Product Details:
|
| Warranty: | 3 Months | Anode Material: | NCM |
|---|---|---|---|
| Chargeable: | Yes | Application: | Toys, Power Tools, Home Appliances, Consumer Electronics, BOATS, Golf Carts, SUBMARINES, Electric Bicycles/Scooters, Electric Folklifts, Electric Vehicles, Electric Wheelchairs |
| Battery Size: | 18*650 | Weight: | 93g |
| The Charging Ratio: | 0.2~2C | The Discharge Rate: | 0.2~2C |
| Storage Type: | -5~35℃ | Battery Type: | Rechargeable Li-ion Battery |
| Port: | YANTIAN | ||
| High Light: | Li Ion Lithium Battery Pack,3.7v Lithium Ion Battery,Rechargeable Lithium Ion Battery |
||
| # | Item | Specifications |
| 1 | Nominal Capacity | 2200mAh 0.2C Discharge |
| 2 | Minimum Capacity | 2100mAh 0.2C Discharge |
| 3 | Nominal Voltage | 3.7V |
| 4 | Charge Current |
Standard Charge:0.5C Rapid Charge:1.0C |
| 5 | Standard Charging Method | 0.5C CC(Constant Charge)charge to 4.2V, then CV(Constant Voltage 4.2V)charge till charge current decline less than 0.01C |
| 6 | Charging Time |
Standard Charging: Approx. 5hours Rapid Charging: Approx. 2.5hours |
| 7 | Max. Charge Current | Constant Current 1C5A Constant Voltage 4.2V 0.01C5A Cut-off |
| 8 | Max. Discharge Current | Constant Current 1.0C5A End Voltage 3.0V |
| 9 | Standard discharge Current | Constant Current 0.2C5A End Voltage 3.0V |
| 10 | Discharge Cut-off Voltage | 3.0V |
| 11 | Charge Cut-off Voltage | 4.2V |
| 12 | Initial Impedance | Less than 100mo |
| 13 | Weight | 45g |
| 14 | Operating Temperature |
Charging:0-45 Discharging:-20-60 |
| 15 | Storage Temperature | -5-35 |
| 16 | Storage Humidity | Less than 75%RH |
| 17 | Appearance | Without scratch, distortion, contamination, and leakage |
| 18 | Standard Environmental Condition |
Temperature:18-28 Humidity:45-75%RH Atmospheric Pressure:86-106Kpa
|
Application Lithium battery:
Mobile phones, tablets, headsets, smart watches and other smart wearable devices, GPS, electric toys, beauty instruments, aromatherapy machines, LED lights, quadcopters, drones ,etc.
Application Lithium battery pack:
E-bike, power tools, new energy vehicles, medical equipment, digital cameras, measuring instruments, robots, etc.
Tips: If you see our products and have questions about the products, please contact our account manager to send your specific needs, such as voltage, capacity, shape, size, working current, etc. We can customize and meet your needs according to your needs. The best lithium battery matched by the equipment, we are very happy to provide you with test samples, and will reply you as soon as possible, thank you!
